29″ Carbon Rim 30mm Tubeless Hookless Asymmetric ArcX 255g for MTB

0 reviews

$190.00

SKU: EC29-36X Brand:
  • Ultralight Carbon Construction: Toray T700/T800 carbon, XC version just 255g – accelerates and climbs effortlessly.
  • Tubeless Hookless Asymmetric Design:</strong> 36mm outer width, 30mm inner width, 24.5mm height – supports 2.3″–3.1″ tires for maximum grip.
  • Recessed Spoke Hole Technology: Embeds tension deeper into rim, reduces stress concentration, improves fatigue resistance.
  • Optimized Spoke Angle Alignment: Inward curvature matches natural spoke angle – reduces friction, smoother wheel building, longer lifespan.
  • Versatile Weight Options: Available in Ultralight (255g), AM (315g), DH (370g), and E-Bike (410g) – fit your riding style.

Application

Weave

Finish

Nipple Hole Size

Rim Groove Holes

Pressure Relief Hole

Order total:
x
Ask B2B Quote
Add to wishlist

Description

Product Overview

This 29” Carbon Rim for MTB featuring a 36mm outer width, 30mm inner width, and 24.5mm height, the ultralight version weighs just 255g. The tubeless, hookless asymmetric design enhances impact resistance and supports wider tires (2.3″–3.1″) for superior traction. Recessed spoke holes optimize force transmission, reduce stress concentration, and improve fatigue resistance – Carbon Rim ideal for demanding MTB terrain.

Specifications

  • Model: EC29-36X
  • Size: 29 inches
  • ERD: 591 mm
  • Outer Width: 36 mm
  • Inner Width: 30 mm
  • Height: 24.5 mm
  • Material: Toray Carbon T700 / T800
  • Weight:AM: 315 ± 15 g、DH: 370 ± 15 g
  • Ultralight: 255 ± 15 g (UD carbon fiber only)
  • Weight for E-Bike: 410 ± 15 g
  • Max Spoke Tension: 115 – 135 kgf
  • Rider Weight Limit: Standard: 125 kg / 276 lbs、Ultralight: 90 kg / 198 lbs
  • Max Tire Pressure: 40 PSI / 2.75 bar
  • Recommended Tire Width: 2.3″ – 3.1″

Package Includes

1 × 29″ Carbon Rim
